Navgraha SteelsINC supplies 16Mo3 Plates, Sheets & Coils from top international mills like Sail, AMNS, JSPL, Evonith, Nippon Yakin, Outokumpu, Special Metals, VDM, and ATI. A widely used EN 10028-2 pressure vessel grade, 16Mo3 is designed for boilers, refinery vessels, and high-temperature equipment. Every delivery is supported with EN 10204 3.1/3.2 MTCs, IBR approvals, and third-party inspections for compliance in global projects.
In EPC projects, one wrong steel grade can cost millions. Boiler plates like 16Mo3 aren’t just metal sheets
When you’re sourcing boiler and pressure vessel steel sheets, there is no margin for error.
When you’re responsible for sourcing boiler and pressure vessel materials, a wrong delivery can mean shutdown delays
16Mo3 is a Cr-Mo alloy pressure vessel steel with 0.3% molybdenum that provides excellent strength, heat resistance, and corrosion resistance at elevated temperatures.
It is often selected as the European equivalent to ASTM SA 387 Gr 12 Cl 2.
drums, headers, steam lines
pressure vessels, superheaters
reactors, columns, separators
fertilizer equipment, process heaters
tubesheets, shells, end plates
where EN-based compliance is required
| Property | Typical Value | Notes |
|---|---|---|
| Tensile Strength | 440–590 MPa | Good for moderate-high stress service |
| Yield Strength | ≥ 220 MPa | Ensures structural safety |
| Elongation | 19–23% | High ductility for forming |
| Impact Test | 27J at -20°C | Excellent notch toughness |
Provides strength + toughness balance for long service in boilers & vessels.
| Element | Typical Range % | Function |
|---|---|---|
| Carbon (C) | 0.12–0.20 | Strength & hardness |
| Manganese (Mn) | 0.40–0.90 | Improves toughness & weldability |
| Silicon (Si) | 0.35 max | Oxidation resistance |
| Phosphorus (P) | ≤ 0.025 | Low for weldability |
| Sulfur (S) | ≤ 0.010 | Low for crack resistance |
| Chromium (Cr) | 0.30 max | Corrosion resistance |
| Molybdenum (Mo) | 0.25–0.35 | Improves creep strength |
Its Mo-enhanced chemistry allows stable performance in high-pressure, high-heat service.
16Mo3 is specified under EN 10028-2 for weldable pressure vessel steels for elevated temperature service.
Global Equivalents
Available Brands:
Sail, AMNS, JSPL, Evonith, Nippon Yakin, Outokumpu, Special Metals, VDM, ATI
This ensures multi-mill availability for EPC approvals and vendor compliance.
We supply 16Mo3 Plates, Sheets & Coils in:
Buyers get optimized dimensions to reduce fabrication waste and cost.
Provides thermal stability, oxidation resistance, and long service reliability.
Navgraha provides ready-to-use, fabrication-friendly plates for EPC and OEM buyers.
A trusted partner for boiler manufacturers, refineries, and EPC projects.
Multiple supply variants make 16Mo3 versatile for refinery, boiler, and chemical applications.
Navgraha SteelsINC exports 16Mo3 Plates, Sheets & Coils to EPC contractors, boiler manufacturers, and refineries across global markets.
Key Export Destinations:
Packing Standards:
Ensures safe, traceable, and compliant shipments worldwide
Choose 16Mo3 steel when:
This makes 16Mo3 an ideal choice for European and international boiler projects.
Every supply of 16Mo3 comes with:
Buyers receive full compliance & inspection-backed confidence.
Up to ~560°C in continuous service.
Yes, it is comparable to ASTM SA 387 Gr 12 Cl 2.
440–590 MPa.
Minimum 220 MPa.
Yes, we supply plates, coils, and sheets.
Sail, AMNS, JSPL, Evonith, Nippon Yakin, Outokumpu, Special Metals, VDM, ATI.
Yes, IBR approval is available.
Yes, for sour service projects.
Yes, SGS, BV, TÜV, Lloyd’s, and DNV are available.
EN 10028-2.
Yes, UAE, Saudi, Oman, and Qatar are major markets.
6 mm to 120 mm, cut-to-size available.
Yes, it offers good resistance to hydrogen-induced corrosion.
Pricing depends on size, thickness & certification – request a live quote.
Navgraha SteelsINC supplies 16Mo3 Plates, Sheets & Coils with:
Global delivery to GCC, Africa, Asia & Europe
