Navgraha Steels INC is a trusted stockist and exporter of SA 516 Gr 60/70 Dual Certified Plates, Sheets & Coils, sourced from leading mills like Sail, AMNS, JSPL, Evonith, Nippon Yakin, Outokumpu, Special Metals, VDM, and ATI. Dual certification offers buyers the flexibility to meet specifications of both Grade 60 and Grade 70 in a single material, reducing procurement risk and ensuring compliance with multiple project requirements.
In critical boiler and pressure vessel projects, one wrong certificate can lead to shutdown delays, audit failures, and millions in losses.
In boiler and pressure vessel projects, even a small error in certification can lead to shutdowns, audit delays, and expensive re-sourcing.
In large boiler and refinery projects, one wrong certification can mean audit rejection, costly delays, and re-sourcing headaches.
Dual certification means that the steel plates, sheets, or coils meet the chemical and mechanical requirements of both SA 516 Gr 60 and Gr 70.
Procurement Benefit: Simplifies sourcing for EPC contractors handling multi-standard projects.
covering both Gr 60 and Gr 70 standards in one stock
tanks, separators, exchangers
steam drums, heat recovery units
reactors, columns, pressure lines
onboard boilers and storage tanks
simplified procurement for multi-grade approvals
| Property | Gr 60 Requirement | Gr 70 Requirement | Dual Certified Plate |
|---|---|---|---|
| Tensile Strength | 415–550 MPa | 485–620 MPa | Meets both ranges |
| Yield Strength | ≥ 220 MPa | ≥ 260 MPa | Complies with Gr 70 |
| Elongation | 21–23% | 17–21% | ≥ 17% (satisfies both) |
| Impact Testing | Optional | Optional | Available on request |
This ensures one product covers dual specifications, eliminating uncertainty in material selection.
| Element | Max % (Typical) |
|---|---|
| Carbon (C) | 0.23–0.27 |
| Manganese (Mn) | 0.60–1.30 |
| Phosphorus (P) | 0.035 |
| Sulfur (S) | 0.035 |
| Silicon (Si) | 0.13–0.45 |
Carefully balanced chemistry ensures plates are compliant with both Grade 60 & Grade 70, making them a versatile choice for global projects.
SA 516 Gr 60/70 Dual Certified plates comply with ASTM A516 / ASME SA516 standards, making them suitable for boiler and pressure vessel construction worldwide.
Global Equivalents
Available Brands at Navgraha Steels INC:
This multi-mill sourcing ensures buyers can meet AVL (Approved Vendor List) requirements across domestic and export projects.
We maintain an extensive ready stock of SA 516 Gr 60/70 dual certified plates:
This range allows EPC contractors, fabricators, and stockists to order exact dimensions, minimizing wastage and lead time.
Dual certified steel ensures buyers can meet Gr 60 or Gr 70 conditions with one plate order, cutting procurement complexity
Navgraha Steels INC supports fabrication-ready supply, saving time for project execution
Buyers gain flexibility, reliability, and faster approval clearance when sourcing from Navgraha Steels INC.
These variants help buyers satisfy EPC specs and global project standards without sourcing multiple grades.
Navgraha Steels INC exports SA 516 Gr 60/70 Dual Certified Plates, Sheets & Coils to leading global markets:
Packaging Standards:
Buyers get safe transport, compliance assurance, and on-time delivery.
Dual certification is ideal for
Choosing dual certified plates ensures cost savings, faster approvals, and greater flexibility.
Every dual certified order comes with:
Buyers receive traceable, globally accepted documentation with every shipment
Gr 70 has higher tensile and yield strength, making it more suitable for critical applications.
Yes, we supply IBR-approved plates for boiler and pressure vessel applications.
From 6 mm up to 300 mm, with widths up to 3500 mm and lengths up to 12,000 mm.
Yes, along with plates, we stock coils and sheets from reputed mills.
Sail, AMNS, JSPL, Evonith, Nippon Yakin, Outokumpu, Special Metals, VDM, ATI.
Yes, we supply NACE MR0175 & HIC tested plates for sour service.
Yes, its low carbon content ensures excellent weldability.
Yes, we offer CNC cutting, water jet cutting, and shearing services.
EN 10204 3.1/3.2 MTC, IBR approval, NACE, HIC, Charpy test reports.
Yes, we export to UAE, Saudi Arabia, Oman, Qatar, and more.
Ready stock is available for immediate dispatch within India and export orders within 7–15 days.
Prices vary based on size, thickness, and certification. Contact us for the latest quotation.
Yes, SGS, BV, Lloyds, TUV, and other third-party inspections are accepted.
We cater to both small project requirements and large bulk orders.
Looking to buy SA 516 Gr 60/70 Dual Certified Plates, Sheets & Coils?
With Navgraha Steels INC, you get:
